The Advantages of Movex Plastic Flattop Chains in the Pharmaceutical Industry

The Role of Plastic Flattop Chains in the Pharmaceutical Industry

The pharmaceutical industry demands conveyor systems that ensure strict hygiene standards, prevent contamination, and operate reliably under harsh conditions. Movex plastic flattop chains are perfectly suited for these requirements with their outstanding features​​:

• Hygiene and safety: Easy to clean and free of harmful substances.
• Operational efficiency: Enhances production line performance.
• Exceptional durability: Resistant to corrosion and capable of handling high-pressure environments.

---

Criteria for Choosing Plastic Flattop Chains for the Pharmaceutical Industry

a. High-quality materials

Chains must be made materials like POM or HDPE that comply with food and pharmaceutical safety standards.

b. Seamless design

Smooth surfaces without gaps help prevent bacterial growth and ensure product safety.

c. Corrosion resistance

Chains must withstand the cleaning agents frequently used in production line sanitation.

---

Five Movex Plastic Flattop Chain Models for the Pharmaceutical Industry

a. Movex PFX200 Plastic Flattop Chain

• Specifications:
  • Maximum load: 2000 N.
  • Material: Chemical-resistant PFX plastic.
  • Minimum curve radius: 90 mm.
  • Operating temperature: -40°C to +80°C.
  • Maximum speed: 85 m/min​​.
• Applications:
  Ideal for transporting pharmaceutical products and packaging.

b. Movex HTX300 Plastic Flattop Chain

• Specifications:
  • Maximum load: 3000 N.
  • Material: High-temperature-resistant HTX plastic.
  • Minimum curve radius: 120 mm.
  • Operating temperature: -20°C to +100°C.
  • Maximum speed: 70 m/min​.
• Applications:
  Suitable for production lines handling tablets or powders.

c. Movex HPS400 Plastic Flattop Chain

• Specifications:
  • Maximum load: 4000 N.
  • Material: High-performance plastic.
  • Minimum curve radius: 150 mm.
  • Operating temperature: -30°C to +90°C.
  • Maximum speed: 100 m/min​.
• Applications:
  Designed for high-speed packaging and transport systems.

d. Movex CMS250 Plastic Flattop Chain

• Specifications:
  • Maximum load: 2500 N.
  • Material: Anti-slip plastic.
  • Minimum curve radius: 80 mm.
  • Operating temperature: -40°C to +60°C.
  • Maximum speed: 90 m/min​.
• Applications:
  Perfect for transporting slippery items like test tubes.

e. Movex DDS150 Plastic Flattop Chain

• Specifications:
  • Maximum load: 1500 N.
  • Material: Antibacterial DDS plastic.
  • Minimum curve radius: 60 mm.
  • Operating temperature: -30°C to +80°C.
  • Maximum speed: 75 m/min​​.
• Applications:
  Ideal for systems requiring high cleanliness levels.

---

Comparison of Technical Specifications

Product Code	Maximum Load (N)	Material	Minimum Curve Radius (mm)	Operating Temperature (°C)	Maximum Speed (m/min)
PFX200	2000	Chemical-resistant PFX	90	-40 to +80	85
HTX300	3000	High-temperature HTX	120	-20 to +100	70
HPS400	4000	High-performance plastic	150	-30 to +90	100
CMS250	2500	Anti-slip plastic	80	-40 to +60	90
DDS150	1500	Antibacterial DDS plastic	60	-30 to +80	75

---

Real-World Applications

Pharmaceutical Production Lines

• Enhances accuracy and operational efficiency.
• Ensures safe transportation of pharmaceutical products.

Pharmaceutical Packaging

• Maintains high-speed operations with safety intact.

Medical Product Manufacturing

• Ensures cleanliness and hygiene for direct-contact products.

---

Conclusion

Movex plastic flattop chains provide not only reliable transportation solutions but also ensure high safety and efficiency standards for the pharmaceutical industry. With product lines like PFX200, HTX300, and HPS400, Movex helps businesses optimize their production and operations. Contact LDCOM, the official distributor for Movex, for detailed consultation​.
